| Overhead power line clearances |
|
| Maintaining the proper clearance from overhead power lines is not only critical to a safe work environment, it’s the law. Contact your FirstEnergy electric company for power line assistance or questions at 1-888-LIGHTSS. |
| Order your FREE worker safety kit on the FirstEnergy e-SMARTworkers website. |
|
|
|
|
| The deal on clearances |
| Here are some key rules to remember: |
| • |
When working with ladders, scaffolding, or long tools: Keep yourself and all tools and equipment at least 10 feet away from overhead power lines carrying up to 50 kV. As voltage increases, clearance distances also increase. For specific requirements, consult osha.gov. |
| • |
When cranes and derricks are used in construction: Keep the crane boom and load at least 20 feet away from lines up to 350 kV and 50 feet away from lines greater than 350 kV but at or less than 1,000 kV. Always assume the line is energized, and allow nothing closer unless you have confirmed with the utility owner/operator that the line has been de-energized. For specific requirements, consult osha.gov. |
|
| • |
Clearly mark boundaries with tape, signs, or barricades to keep workers and equipment the required distance away. |
|
| • |
Always use a dedicated spotter on the ground to help you stay clear of power lines. |
|
|
If your work requires additional encroachment precautions, call your FirstEnergy electric company well in advance of starting the work. They will take steps to help you work safely. |
| Don’t forget |
| Power lines are not insulated. Always consider them energized and dangerous. Any contact with overhead lines could cause serious injury to equipment operators and ground crew. |
| Would you like to know more? |
| Additional utility safety tips, case studies, instructional videos, and educational tools can all be found, at no charge to you, on FirstEnergy's e-SMARTworkers website. |
|
